Crystallography Group Update 2023-24
Aug 28, 2024
Every year, Diamond produces an Annual Review, covering the scientific, technical, computing and business updates from the facility. The feature that follows has been prepared for our latest review, and looks at work conducted between April 2023 to April 2024.
Working to fully exploit the technical and scientific capabilities to support research over a broad range of topics
Group leader: Joe Hriljac - 2024, Philip Chater 2024
The Crystallography Group comprises the High-Resolution Powder Diffraction beamline (I11), the Extreme Conditions beamline (I15), the X-ray Pair Distribution Function (XPDF) beamline (I15-1), and the Small-Molecule Single-Crystal Diffraction beamline (I19). The staff at the beamlines are not only experts in supporting research at their own beamlines but most have broader knowledge of the other beamlines and available techniques. This allows the group to fully exploit the technical and scientific capabilities to support research over a broad range of topics that include biomaterials, catalysis, energy production and storage, environmental understanding and remediation, and fundamental physics and chemistry. Studies under in situ and operando conditions are common to further enhance the breadth of scientific studies. Major upgrades to I11 and I15-1 started in past years are nearing completion and these will improve the quality of data that can be collected as well as provide greater automation and capabilities for user operations. Operations at I15 and I15-1 in the past have been hampered by problems with the superconducting wiggler that produces the required high energy X-rays but this is now working well and a spare to mitigate future problems has been ordered.
I11 update
- I15 team (L-R): Egor Koemets, Laura Arcidiacono, Annette Kleppe, Allan Ross and Xiaojiao Liu
The high brightness beamline uses monochromatic X-rays in the range of 6 - 25 keV for high-resolution and time-resolved powder diffraction experiments in the first Experimental Hutch (EH1) or for Long Duration Experiments in EH2. The varied science program supports a wide range of studies by chemists, physicists, materials scientists and environmental scientists in particular for non-ambient applications and experiments requiring unusual hardware setups such as toxic/corrosive gas absorption studies at cryogenic temperatures, resonant diffraction at high temperature and time-resolved in operando lithium-ion (Li-ion) battery work.
After running for over ten years, many components such as the monochromator, diffractometer and multi-analyser crystal (MAC) detector began to show signs of wear. An upgrade plan, endorsed by the Scientific Advisory Committee (SAC) and the Diamond Industrial Science Committee (DISCo) at the end of 2018, to replace these components started in 2019 and the new Newport diffractometer was partly installed when site was shut in March 2020. During the course of 2020, the installation and commissioning resumed when possible under the COVID-19 working protocols and finally in January 2021 the last stage, commissioning of the robot sample changer, was completed and the beamline became operational again. Another part of the upgrade was the construction of a new linear position sensitive detector (PSD) using Mythen3 technology and this has now been installed on the beamline and should be in routine use by the middle of 2024. This will lead to the ability for even faster collection of powder patterns for, such as e.g., time-resolved studies.
I15 update
The Extreme Conditions beamline, I15, employs high energy X-rays to explore the structure of materials at high pressures, high and low temperatures, as well as other in situ and in operando conditions. The beamline receives an X-ray continuum from the superconducting wiggler; this allows for experiments that require monochromatic X-rays between 20 and 80 keV. I15 was originally designed to serve the mineral physics community, which it has, whilst also assisting material scientists, chemists and solid-state physicists with their structural investigations, at pressure or otherwise.
I15 continues to offer extensive capabilities and support to users to assist their high-pressure studies. I15 users have pre-experiment access to bespoke assistance and training from our highly skilled staff in diamond anvil cell (DAC) preparation and loading, as well as the opportunity to collaborate in the use of beamline DACs for novice users for I15 experiments. The high-pressure gas loader available at I15 offers users the choice of many possible gases to use as their pressure transmitting media (PTM), allowing them to optimise for hydrostaticity with helium or neon, or choosing a PTM based on desired interactions with the sample at pressure. Loading with hydrogen gas has been planned for some time and this should become feasible later in 2024. The recent addition of the laser heating and resistive heating systems adds further capability – the I15 laser system is capable of quickly ramping the laser power to perturb a sample without delivering too much heat to the bulk. A DECTRIS PILATUS3 X CdTe 2M is now in routine operation and it provides much greater sensitivity to high-energy X-rays and the capability for much faster data collections. The quality of data has led to a resumption of the development of high-pressure single crystal data collection including the project of a Diamond PhD student. Further upgrades to I15 to take full advantage of fast hardware-based scanning and mapping are planned.
I15-1 update
- I15-1 team (L-R): Philip Chater, Dan Irving, Tobias Bird, Anna Herlihy, Andrew Fairley.
The XPDF beamline, I15-1, is dedicated to producing high-quality X-ray scattering data for Pair Distribution Function (PDF) analysis. Operational since 2017, I15-1 has illuminated samples from diverse fields, from Earth sciences to pharmaceuticals, as well as material science and chemistry. XPDF receives X-rays from the inside edge of the wiggler fan, and this light is monochromated and directed to the end station in three energies: 40, 65 and 76 keV. PDF data are collected at high energies to produce the low sample absorption and high Q-range required for successful interpretation. Gaining structural information on amorphous samples is a primary goal of many XPDF experiments, but crystalline samples can also display local structure variations such as defects and disorder, which can be studied via PDF analysis. PDF data collections are rarely available at home institutions, so in order to allow more people to exploit this powerful technique, I15-1 complements the standard proposal route with popular Rapid and Easy Access routes, where PDF data can be collected via a mail-in procedure.
Consisting of a sample position, with an optional sample-changing magazine, and two large area detectors, the end station is highly flexible and has been adapted to many in situ and in operando experiments, including variable temperature, gas flow, hydrothermal synthesis and electrochemical cycling. For more routine measurements, a sample-changing robot with 400 positions is used and was part of the SAC approved upgrade project. The final aspect of the upgrade is a bespoke new detector designed and constructed by the in-house Detector Group. It is based on CdTe sensors that are much more sensitive at high energy and with faster electronics for data readout. The detector is now installed on the beamline and has been used for its first user experiment to collect Bragg data. The Detector Group is fine tuning operation and it is anticipated it will be working to specification late in 2024 and then in routine operation. The equipment upgrades are a synergistic addition to the existing autoprocessing infrastructure and will allow users to collect better data with less manual intervention.
I19 update
The Small-Molecule Single-Crystal Diffraction beamline, I19, uses X-rays in the 5 – 25 keV energy range to determine the structures of small-molecule and extended three-dimensional systems, e.g. such as metal-organic frameworks, with single-crystal diffraction techniques. These methods can be applied to the characterisation of novel materials or for investigating the variation in the structure of a crystalline material under an external physical influence such as a change in temperature, the exposure to a gas, photoexcitation or through the application of high-pressure.
The use of the robotic sample changer, and remote access, is now well established in Experimental Hutch 1 (EH1) of the beamline, where pre-mounted samples are sent to Diamond under cryogenic storage, and users then run their beamtime from their home institutions. This mode of operation makes it possible to carry out chemical crystallography studies in a more responsive manner as beamtime can be scheduled in more regular, and shorter, periods. Experiments in Experimental Hutch 2 (EH2) cover a much wider range of sample environments including photoexcitation, high pressure, gas flow, very low temperatures and high static electric fields. The application of electric fields to materials can result in a variety of responses that may have important technological applications, spanning electronic and ionic conductivity to piezoand ferro-electricity. Upgrades to the original mirrors was made in 2021, giving much improved performance in both beam focus and positional stability. During 2021, a DECTRIS EIGER2 X CdTe 4M was installed in EH2 and this is now in regular use producing vastly superior data over the older system. These equipment upgrades and extensive efforts by beamline staff and students in collaboration with users has also brought the technique of serial crystallography to the beamline and this is now an area of active improvement given its scope to support materials discovery.
